Professional low cost fr4 printed circuit board pcb with pcba assembly service

FOB Reference Price:Get Latest Price
$1.00 - $10.00 / Piece | 1 Piece/Pieces shenzhen pcb manufacture (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Model Number:
hc91
Brand Name:
Fulltronics, OEM
Min. Hole Size:
0.2 mm, 0.25mm
Max size of board:
600*1200mm
Surface Finishing:
HASL OSP Immersion Tin/Gold/Silver Carbon Oil, Immersion gold/HASL/OSP
ISO Certificate 1:
ISO9001:2000
pcb assembly ISO Certificate 2:
ISO 14001 PCB board
ISO Certificate:
ISO / TS 16949:2002
pcb QC:
Flying Probe Testing, E-test
Non disclosure agreement:
yes
Applications:
Industrial/Consumer electronical
Min. Line Width:
3mi
Copper Thickness:
0.5oz-6oz
Min. Line Spacing:
0.003"
Board Thickness:
1.2mm
Base Material:
FR4, CM-1 CM-3 FR-4 FR-1 AL-PCB
Supply Ability
Supply Ability:
1000000 Square Meter/Square Meters per Month shenzhen pcb manufacture
Packaging & Delivery
Packaging Details
vacuum packing, anti-static package or in your requirements.
Port
Shenzhen, Hong Kong
Lead Time :
1-2 weeks
Video Description
Product Description





Our production capacity

PCB Item Manufacture Capacity
   Layer Counts   1--20L
   Base Material   FR4,High-TG FR4,CEM3,aluminum,High Frequency(Rogers,Taconic,Aron,PTFE,F4B)
   Material Thickness(mm)   0.40, 0.60, 0.80, 1.00, 1.20, 1.50, 1.60, 2.0, 2.4, 3.2
   Max board size(mm)   1200x400mm
   Board Outline Tolerance   ±0.15mm
   Board Thickness   0.4mm--3.2mm
   Thickness Tolerance   ±8%
   Minimum line/space   0.1mm
   Min Annular Ring   0.1mm
   SMD Pitch   0.3mm
Holes
   Min  Hole Size(mechanical)   0.2mm
   Min Hole Size(laser hole)   0.1mm
   Hole Size Tol (+/-)   PTH:±0.075mm;NPTH: ±0.05mm
   Hole Position Tol   ±0.075mm
Plating
   HASL/LF HAL   2.5um
   Immersion Gold   Nickel  3-7um  Au:1-5u''
   Surface Finish   HAL,ENIG,Plated Gold,Immersion Gold,OSP
   Copper
   Copper Weight   0.5--6oz
Color
   Solder mask   Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue
   Silk screen   White, Black, Blue,Yellow
   Acceptable File Format   Gerber file,Powerpcb,CAD,AUTOCAD,ORCAD,P-CAD,CAM-350,CAM2000
   Certificate   ROSH,ISO9001,UL



LEAD TIME FOR PRODUCTION ORDERS:



Sample Lead time

Mass production lead time

Single sided PCB

1~3

4~7

Double sided PCB

2~5

7~10

Multilayer PCB

7~8

10~15

PCB and Assembly

8~15

15~20



Professional low cost fr4 printed circuit board pcb with pcba assembly serviceh.jpgi.jpgj.jpgk.jpg

OEM/ODM/EMS Services for PCBA:

  • PCBA, PCB Board assembly: SMT & PTH & BGA
  • PCBA and enclosure design
  • Components sourcing and purchasing
  • Quick prototyping
  • Plastic injection molding
  • Metal sheet stamping
  • Final assembly
  • Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)
  • Custom clearance for material importing and product exporting

Capability - SMT

  • Lines                   9(5 Yamaha,4KME)
  • Capacity                 52 million placements per month
  • Max Board Size           457*356mm.(18”X14”)
  • Min Component size       0201-54 sq.mm.(0.084 sq.inch),long connector,CSP,BGA,QFP
  • Speed                   0.15 sec/chip,0.7 sec/QFP

Capability - PTH

  • Lines                   2
  • Max board width         400 mm
  • Type                   Dual wave
  • Pbs status               Lead-free line support
  • Max temp               399 degree C
  • Spray flux               add-on
  • Pre-heat                 3

       Product Type

















          To ensure an accurate quote, be sure to include the following information for your project:

          •Complete GERBER files including the BOM list
          •Other file types (Altium,Protel,OrCAD)
          •"Read Me" notes for additional fabrication information
          •Quantities
          •Turn time
          •Panelization Requirements
          •Materials Requirements
          •Finish requirements
          Your custom quote will be delivered in just 2-24 hours, depending on the design complexity.











                              We purchase material from Original Company and distributers.
                              We make products by strict engineer processes.
                              We have strict inspection processes.
                              We send products by vaccum package,antistatic package and carton box.
